Brake Disc

Code: BOSCH0986478590
GH₵1,206.18
In stock

Specifications

BrandBosch
Brake disc thickness mm24
Centering diameter mm61
Fulfils ece normECE-R90
MachiningAlloyed/High-carbon
Supplementary article info 2with bolts/screws
SurfaceCoated
Payloadfor increased payload
Left right hand drive vehiclesfor right-hand drive vehicles
Braking driving dynamicsfor vehicles with ESP
Rim size inch15.0; 16.0
Bore diameter up to mm13,6
Tecdoc engine number11428; 13308; 13309; 13310; 14334; 16190; 16191; 16208; 16269; 16278; 16340; 16342; 16345; 16346; 16347; 16349; 16350; 16351; 16353; 16354; 16355; 16356; 16358; 16361; 16363; 16370; 16373; 16531; 16532; 16533; 17489; 17494; 17498; 18302; 18303; 18421; 18536; 18538; 20049; 20050; 20051; 20391; 20707; 20829; 20973; 20988; 21136; 21194; 21208; 21213; 21214; 21215; 21256; 21294; 22184; 22185; 22192; 25691; 26333; 26524; 27174; 28005; 29265; 31047; 31423; 31425; 32413; 33761; 34129; 35373; 37231; 38781; 38783; 44657; 45384
Rim hole number4
Engine codeD4F 742; F3P 676; F3R 611; F3R 729; F3R 769; F4R 732; F4R 740; F4R 741; F4R 746; F4R 770; F4R 771; F9Q 733; F9Q 738; F9Q 740; F9Q 746; F9Q 748; F9Q 796; F9Q 800; F9Q 814; H4D 480; H4M 630; K4M 708; K4M 712; K4M 754; K4M 760; K4M 761; K4M 762; K4M 764; K4M 768; K4M 856; K9K 722; K9K 732; K9K 734; K9K 762
Construction year from199509; 199803; 199805; 199806; 199810; 199903; 199904; 199909; 199910; 200005; 200009; 200010; 200011; 200101; 200201; 200211; 200310; 200409; 200410; 200505; 200510; 200511; 200701; 200708; 201011; 201501; 201505; 201904
Construction year to199704; 199809; 199902; 200102; 200210; 200304; 200710; 200712; 200810; 200812; 200904; 200905; 200910; 201412; 201712; 201811; 201812; 201912; 202112; 202201; 202206; 202312
Fitting positionFront Axle
Height mm44
Outer diameter mm280,3
Minimum thickness mm21,8
Brake disc typeVented
Bolt hole circle mm100
Number of holes4

Compatible Vehicles:

Brake Disc OE Numbers
