Brake Drum
Code: TRWDB4003
GH₵1,034.69
Not available
Specifications
BrandTrw
Bore diameter 1 mm14,5
Centering diameter mm57
Braking driving dynamicsfor vehicles with ABS
Inner brake drum diameter mm230
Max brake drum reboring dimension mm230,9
Inner brake drum height mm59
Outer brake drum diameter mm273
Total brake drum height mm76
Bore diameter 2 mm10,3
Transmission typeFully Automatic
Transmission codeATM
Construction year from196808; 197806; 197808; 198008; 198108; 198207; 198307; 198309; 198601; 198609; 198709; 198907
Construction year to196508; 196608; 196807; 197108; 197801; 198007; 198104; 198108; 198209; 198408; 198712; 198808; 199205; 199407; 199705
Fitting positionRear Axle
Bolt hole circle mm100
Number of holes4
