Piston
Code: MAHLE028PI00100002
GH₵3,353.37
Not available
Specifications
BrandMahle
Supplementary article info 2with cooling duct
SurfaceCoated
Production number81 L 156
Component number3. DSF 3.0 Cr
Cylinder bore mm81,5
Bolt head diameter mm26
Machinedwith cut-out for oil jet
Bolt length mm66
Compression height mm45,8
Piston clearance mm0,07
Recess depth 1 mm12,7
Recess diameter mm50,9
Top land height mm12,1
Engine codeCAAA; CAAB; CAGA; CAGB; CAGC; CAHA; CAHB; CBAA; CBAB; CBBB; CBDA; CBDB; CBDC; CDBA; CEGA; CJAA; CMEA
Length mm68,8
