Piston
Code: MAHLE021PI00113002
GH₵5,247.91
Not available
Specifications
BrandMahle
Supplementary article info 2with cooling duct
SurfaceCoated
Net weight g577
Packaging height cm12,80
Packaging length cm9,5
Packaging width cm9,50
Production number84 L 165
Component number3. DSF 2.0 Cr
Cylinder bore mm84,5
Bolt head diameter mm32
Machinedwith cut-out for oil jet
Bolt length mm65
Compression height mm47,91
Connecting rod designTrapezoidal Connecting Rod
Piston clearance mm0,07
Recess depth 1 mm14,9
Recess diameter mm49
Top land height mm9
Valve pocket depth 1 mm0,4
Engine codeM9R; M9R 630; M9R 740; M9R 742; M9R 744; M9R 750; M9R 760; M9R 761; M9R 780; M9R 782; M9R 784; M9R 786; M9R 788; M9R 800; M9R 802; M9R 804; M9R 805; M9R 809; M9R 816; M9R 832; M9R746; M9R748; M9R762; M9R763; M9R812; M9R815; M9R820
Length mm76
