Starter

Code: BOSCH1986S00940
GH₵5,762.96
Not available

Specifications

BrandBosch
Length mm198
Thread size 2M8x1,25
Vehicle equipmentfor vehicles with start-stop function; for vehicles without air conditioning; for vehicles without start-stop function
Manufacturer restrictionHITACHI
Emission standardEuro 5
Number of mounting bores2
Bore diameter mm8,5
Flange diameter mm64
Rated power kw1,2
Rotation directionClockwise rotation
Number of threaded holes1
Clamp30,50
Position degreerechts
Pinion rest position mm11
Bore diameter 2 mm9,1
Jaw opening angle measurement degree127
Mounting angle degrees46
Mounting bore angle measurement degree46
Starter typeSelf-supporting
Voltage v12
Tecdoc engine number12791; 18571; 20248; 20272; 20277; 21040; 21045; 21046; 23921; 28632; 31245; 31895; 31896; 33162; 33163; 34922; 47989
Engine code312 A1.000; 312 A1.000<M20>; 312 B3.000; 940 B7.000
For oe number51890631; 51890632; 52100116
Number of teeth10
Construction year from200307; 200310; 200410; 200510; 200612; 200809; 200901; 200903; 200909; 200910; 201003; 201005; 201009; 201107; 201202; 201203; 201409; 201501; 201507; 201601; 201603; 201705; 201801; 201901; 201903; 201905; 201906; 201909
Construction year to200109; 200306; 200312; 200609; 200712; 200912; 201007; 201009; 201012; 201110; 201111; 201112; 201212; 201308; 201312; 201412; 201512; 201602; 201606; 201608; 201704; 201712; 201808; 201812
Transmission typeManual Transmission
