Starter

Code: BOSCH1986S00575

GH₵3,013.36

Not available

Specifications

BrandBosch

Length mm198

Thread size 2M8X1,25

Vehicle equipmentfor vehicles without start-stop function

Manufacturer restrictionMITSUBISHI

Number of mounting bores2

Bore diameter mm9,2

Flange diameter mm65,4

Rated power kw1,4

Rotation directionClockwise rotation

Number of threaded holes2

Clamp30

Position degreelinks

Pinion rest position mm14

Bore diameter 2 mm9,2

Jaw opening angle measurement degree73

Mounting angle degrees38

Mounting bore angle measurement degree38

Starter typeSelf-supporting

Thread size 3M8X1,25

Voltage v12

Tecdoc engine number17509; 19824; 19913; 20147; 23537; 23773; 25061; 25064; 25092; 25093; 25096; 25690; 27064; 27967; 28622; 29698; 31068; 31071; 31490; 32307; 32530; 33707; 33791; 34426; 34740; 35380; 35429; 35430; 35623; 35633; 35775; 35776; 36833; 45129

Engine code8HZ<DV4TD>; 9HJ<DV6DTED M>; 9HK<DV6ETED M>; 9HN<DV6ETED4>; 9HT<DV6BUTED4>; 9HU<DV6UTED4>; 9HW<DV6BTED4>; 9HW<DV6BUTED4>; 9HX; BHS<DV6FDU>; BHV<DV6FDU>

For oe number5802 FG; 5802FG

Number of teeth11

Construction year from200309; 200410; 200506; 200509; 200605; 200702; 200706; 200801; 200805; 200903; 201001; 201004; 201006; 201008; 201009; 201010; 201011; 201012; 201101; 201106; 201109; 201201; 201203; 201502; 201503; 201510; 201807; 201809; 201811; 201812

Construction year to200505; 200508; 200612; 200706; 200804; 200812; 200901; 200902; 200906; 200908; 201001; 201004; 201012; 201101; 201103; 201104; 201110; 201111; 201112; 201202; 201204; 201305; 201306; 201307; 201401; 201412; 201503; 201504; 201506; 201512; 201612; 201712; 201812; 201912; 202009; 202012; 202102; 202204; 202212
