Brake Drum

Code: BOSCH0986477040
GH₵1,020.61
Not available

Specifications

BrandBosch
Fitting positionRear Axle
Bolt hole circle mm100
Centering diameter mm50,3
Number of holes4
Supplementary article info 2with wheel hub
Braking driving dynamicsfor vehicles without ABS
Inner brake drum diameter mm200
Inner brake drum height mm60
Outer brake drum diameter mm228
Total brake drum height mm84
Tecdoc engine number17581; 29513; 29515; 29516; 39515; 39517; 4724; 4809; 8405
Engine code15 TD<T4EC1 Turbo>; 17 D<4EE1>; B16NE; BE<DOHC SFI>; C10YE<SOHC MPFI>; C16SEL<DOHC SFI>; CJ<DOHC SFI>; X 15 D<4EC1>; X 15 TD<4EE1 Turbo>; X10YFH<VHC>
Construction year from198305; 198501; 198603; 198701; 198709; 198803; 198904; 199001; 199009; 199109; 199409; 199512; 199601; 199604; 199609; 199904
Construction year to199408; 199612; 199808; 199908; 200008; 200109; 200207; 200302; 200610; 200811

Compatible Vehicles:

Brake Drum OE Numbers
