Starter
Code: BOSCH0986023480
GH₵3,080.08
Not available
Specifications
BrandBosch
Number of mounting bores3
Bore diameter mm11,5
Flange diameter mm112
Rated power kw1,3
Rotation directionClockwise rotation
Number of threaded holes0
Clamp30
Position degreerechts
Pinion rest position mm14
Bore diameter 2 mm11,5
Bore 3 mm11,5
Jaw opening angle measurement degree26
Mounting angle degrees11
Mounting bore angle measurement degree11
Starter typeSelf-supporting
Voltage v12
Tecdoc engine number16213; 16218; 18841; 18962; 21314
Number of teeth10
Engine codeXFU<ES9A>; XFW<ES9J4S>; XFW<M15>
Construction year from199912; 200210; 200405; 200410
Construction year to200211; 200406; 200509; 200605; 200612; 200704; 200709; 200901; 200902; 200904; 200906
Length mm205
