Starter

Code: BOSCH0986018880

GH₵2,438.94

Not available

Specifications

BrandBosch

Length mm220

Thread size 1M8x1.25

Thread size 2M8x1.25

Manufacturer restrictionBosch; MARELLI; VALEO

Number of mounting bores1

Bore diameter mm11

Flange diameter mm66

Rated power kw1,1

Rotation directionClockwise rotation

Number of threaded holes2

Climate zonesfor cold climate zones; not for cold climate zones

Clamp30,50

Position degreelinks

Pinion rest position mm11,5

Jaw opening angle measurement degree35

Mounting angle degrees55

Mounting bore angle measurement degree55

Starter typeSelf-supporting

Voltage v12

Tecdoc engine number10187; 15650; 16166; 18897; 25965; 36285; 4400; 9476

Engine code178 A8.011<M6>; 178 D2.011<M27>; 182 A4.027<M5>; 182 A4.027<M6>; 182 B6.000<M2 CF3>

For oe number51868757

Number of teeth9

Construction year from199603; 199610; 199710; 199711; 199811; 199903; 199910; 199911; 200004; 200006; 200008; 200010; 200110; 200201; 200204; 200301; 200401; 200510; 200604

Construction year to199804; 199810; 199902; 200005; 200009; 200010; 200109; 200112; 200203; 200312; 200409; 200412; 200509; 200712; 200812; 201012; 201112

Vehicle identification number vin from0022619

Transmission typeAutomatic Transmission; Manual Transmission

Ricambi number from183621; 2053947; 2063955; 302233; 3297145; 3298003; 490885; 5057081; 6006952

Ricambi no up to2017058; 242264; 3058719; 3298003; 3302897; 4139410; 490884; 4998979; 6000194

Ricambi number4142893
