Starter

Code: BOSCH0986017490

GH₵4,641.75

Not available

Specifications

BrandBosch

Length mm274

Thread size 1M10x1.5

Manufacturer restrictionBosch

Number of mounting bores2

Bore diameter mm12

Flange diameter mm110

Rated power kw2,2

Rotation directionClockwise rotation

Number of threaded holes1

Clamp30

Position degreerechts

Pinion rest position mm27

Bore 3 mm12

Jaw opening angle measurement degree130

Mounting angle degrees35

Mounting bore angle measurement degree35

Starter typeSelf-supporting

Voltage v12

Tecdoc engine number16874; 20453; 31263; 39443; 7229; 7235

Engine code8140.07.2700; 8140.07.2701; 8140.07.2710; 8140.07.2711; 8140.07.2712; 8140.07.2713; 8140.27R.27..; 8140.27S.2700; 8140.27S.2701; 8140.27S.2710; 8140.27S.2711; 8140.27S.2720; 8140.27S.2721; 8140.27S.2730; 8140.27S.2731; 8140.27S.2750; 8140.27S.2751; 8140.27S.2760; 8140.27S.2761; 8140.27S.2770; 8140.27S.2771; 8140.27S.2801; 8140.27S.2811; 8140.27S.2885; 8140.27S.3750; 8140.27S.3751; 8140.27S.3760; 8140.27S.3761; 8140.27S.3770; 8140.27S.3771; 8140.27S.3780; 8140.47.2711; 8140.47.2721; 8140.47.2731; 8149.03.3791; 8149.03.4000

For oe number99451753

Number of teeth9

Construction year from197804; 198502; 198907; 198909; 199010; 199102; 199207; 199605; 200209; 200210; 200309; 200510

Construction year to198906; 199006; 199009; 199604; 199704; 199803; 199905; 199907; 200608

Vehicle identification number vin to8316848

Vehicle identification number vin from8316849

Vehicle type35.12; 49.12; 60.12
