Starter

Code: BOM-Prestolite860814
Includes multiple items (set)
GH₵7,213.08
Not available

Specifications

BrandBom-prestolite
Connector typeGrounded
Quantity1
Number of mounting bores3
VersionPremium
Weight g8400
Flange diameter mm89
Rated power kw4
Rotation directionClockwise rotation
Connector clampB+
Pinion rest position mm29
Housing diameter mm95
Closing angle degree30
Voltage v24
Number of teeth10
Bolt hole circle mm127

Compatible Vehicles:

Starter OE Numbers

This Product Includes:

RelayBOM-PrestoliteThis product is not available ×1
Solenoid Switch, starterBOM-PrestoliteThis product is not available ×1
Pinion, starterBOM-PrestoliteThis product is not available ×1
Armature, starterBOM-PrestoliteThis product is not available ×1
CoilBOM-PrestoliteThis product is not available ×1
