Brake Disc

Code: BLUEPRINTADR164331
GH₵1,496.39
Not available

Specifications

BrandBlue print
Fitting positionFront Axle
Bolt hole circle mm108
Brake disc thickness mm28
Brake disc typeinternally vented
Centering diameter mm61
Minimum thickness mm25,8
Outer diameter mm308
SurfaceCoated
Thickness mm47
Weight kg5,2
Number of mounting bores2
Tecdoc engine number16218; 16288; 16377; 17057; 17059; 17060; 17061; 18286; 18287; 18288; 20976; 20977; 23108
For oe number82 00 570 677
Rim hole number5
Construction year from200310

Compatible Vehicles:

Brake Disc OE Numbers
