Brake Disc

Code: ATE24031201511
GH₵1,752.46
Not available

Specifications

BrandAte
Fitting positionRear Axle
Height mm64,8
Bolt hole circle mm108,0
Brake disc thickness mm11,9
Brake disc typesolid
Centering diameter mm68,0
Inner diameter mm178,0
Minimum thickness mm10,0
Number of holes5
Outer diameter mm288,0
SurfaceCoated
Bore diameter mm16,5
Construction year from200003; 200008; 200011; 200107; 200108; 200109; 200111; 200112; 200206; 200209; 200303; 200307; 200402; 200404; 200505; 200509; 200512
Construction year to200404; 200602; 200707; 200901

Compatible Vehicles:

Brake Disc OE Numbers
