Brake Disc

Code: ATE24011201271
GH₵806.63
In stock

Specifications

BrandAte
Fitting positionFront Axle; Rear Axle
Height mm40,5
Bolt hole circle mm98,0
Brake disc thickness mm12,0
Brake disc typesolid
Centering diameter mm59,0
Inner diameter mm123,0
Minimum thickness mm10,2
Number of holes4
Outer diameter mm257,5
SurfaceCoated
Test markE1 90R-02C0165/0815
Rimsfor light alloy rims
Braking driving dynamicsfor vehicles with ABS
Bore diameter mm13,0
Not for vehicle configuration line variantCITY CROSS; CROSS
Equipment codeSerie 3
Catalytic converter typewithout catalytic convertor
Construction year from198801; 199001; 199003; 199302; 199305; 199311; 199403; 199606; 199705; 199706; 199904; 199910; 200010; 200307; 201504; 201506
Construction year to199112; 199301; 199304; 199310; 199509; 199612; 199705; 199812; 199909; 200009; 200110; 200306; 200307; 200511; 201106
Transmission typeAutomatic Transmission; Manual Transmission

Compatible Vehicles:

Brake Disc OE Numbers
